Description
Bussmann FWX-70A High Speed Fuse
Bussmann High Speed Fuse, North American Style, Series: FWX, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 70 A, 600 VAC, 50 kAIC Interrupt, Blade End Terminal, Flush/Stud Mount, Cartridge Body Type, Single Element, Ceramic, 1.22 in Dia x 3.13 in L Body Size
Additional Description: BUSS-FWX-70A BUSS HIGH SPEED FUSE
Catalog Description: Eaton Bussmann series FWX high speed fuse, 600V, 70A RMS, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
Specifications
| UNSPSC | 39121625 |
|---|---|
| Amperage Rating | 70 |
| Amperage Rating | 70 A |
| Body Type | Cartridge |
| Body Type | Cylindrical |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 20/200 |
| Interrupt Rating | 50 kAIC |
| Interrupt Rating | 50/200 |
| Material | Ceramic |
| Mounting type | Bolt-In/Flush/Stud |
| Mounting type | Flush/Stud |
| Mounting type | Stud |
| Rejection/Non-Rejection | Non-Rejection |
| Series | FWX |
| Terminal Type | Blade |
| Terminal Type | Blade End |
| Type | Fast Acting |
| Type | North American Style |
| Voltage Rating | 250 |
| Voltage Rating | 600 VAC |
