Description
Bussmann JM60200-2MW16 Modular Fuse Block
Bussmann Fuse Block, Modular, Series: JM Series, 600 V, 110 to 200 A, 2 Pole, Class: J, Wired, 6 AWG to 250 kcmil, 14 to 4 AWG, 8 to 4 AWG, (12) 14 to 10 AWG Wire, DIN Rail/Panel Mount, -40 to 120 deg C, Thermoplastic, Gray, 6.8 in L x 3.8 in W x 2.6 in H
Additional Description: BUSS-JM60200-2MW16 CLASS J 600V 200A FUSE BLOCK ASSY 2P - 2
Catalog Description: Eaton Bussmann series JM modular fuse block, 110-200 A, Two-pole, Class J, 200 kAIC, 600 V
Specifications
| UNSPSC | 39121629 |
|---|---|
| Amperage Rating | 110 to 200 |
| Amperage Rating | 110 to 200 A |
| Class | J |
| Color | Gray |
| Connection type | Wired |
| Dimensions | 6.8 in L x 3.8 in W x 2.6 in H |
| Material | Thermoplastic |
| Mounting type | DIN Rail/Panel |
| Number of Poles | 2 |
| Series | JM Series |
| Temperature Rating (Degrees F) | -40 to 120 |
| Temperature Rating (Degrees F) | -40 to 120 deg C |
| Type | Modular |
| Type | Power Distribution |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
| Wire Size | 6 AWG to 250 kcmil, 14 to 4 AWG, 8 to 4 AWG, (12) 14 to 10 AWG |
