Description
Bussmann KTS-R-110 Fast Acting Fuse
Bussmann Limitron Fuse, Current Limiting Fast Acting Low Voltage, Series: KTS-R, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Rejection, 110 A, 600 V, 200 kAIC Interrupt, Class: RK1, Knife Blade End Terminal, Holder Mount, Cartridge Body Type, Single Element, Melamine Glass Tube, 1.5 in Dia x 9.63 in L Body Size
Additional Description: BUSS-KTS-R-110 (N) LIMITRON FAST ACTING FUSE NON-CANCELABLE, NON-RETURNABLE
Catalog Description: Eaton Bussmann series KTS-R fuse, LIMITRON Fast-acting fuse, Panelboards, 110 A, 1, Class RK1, Non-indicating, 200 kAIC at 600 Vac, Standard, 600 V
Specifications
| UNSPSC | 39121626 |
|---|---|
| Amperage Rating | 110 |
| Amperage Rating | 110 A |
| Body Type | Cartridge |
| Class | RK1 |
| Indicating/Non-Indicating | Non-Indicating |
| Interrupt Rating | 200 |
| Interrupt Rating | 200 kAIC |
| Material | Melamine |
| Material | Melamine Glass Tube |
| Mounting type | Holder |
| Rejection/Non-Rejection | Rejection |
| Series | KTS-R |
| Terminal Type | Knife Blade |
| Terminal Type | Knife Blade End |
| Type | Current Limiting Fast Acting Low Voltage |
| Type | Current Limiting Low Voltage |
| Voltage Rating | 600 |
| Voltage Rating | 600 V |
