Description
Quick-turn, Made in USA Fiber Patch Cables
Bulk Discount and Free shipping over $250
Over 5000 connectors and 500,000 FT of fiber in stock!
- Flame-retardant PVC (Riser) Jacket enhances safety
- Utilize G.657.A1 Bend Insensitive Fiber with a 10mm Min. Bend Radius
- Precision Zirconia Ferrule Connectors ensure minimal loss
- Duplex Zipcord improves Mechanical Performance and reduces Crimping Risk
- Optical Testing ensures reliable Network Performance
- Comply with TIA-604 (FOCIS) Standards
- Suitable for Aerial, Direct Buried, and Duct Installation
Efficient Connectivity: Affordable High-Quality 9/125μm Single-Mode Bend-Insensitive Fiber Optic Cable
The 9/125μm OS2 single-mode bend-insensitive fiber optic cable offers superior performance with reduced attenuation when bent or twisted, making the installation and maintenance of fiber optic cables more efficient. This cable also provides space-saving benefits for high-density cabling in various environments, including data centers, enterprise networks, telecom rooms, server farms, and cloud storage networks. It is well-suited for interconnecting pre-terminated cassettes in main distribution, horizontal distribution, and equipment distribution areas where fiber patch cables are essential.
Specifications
| Connector Type | LC UPC to SC UPC |
|---|---|
| Fiber Grade | G.657.A1 (Compatible with G.652.D) |
| Fiber Mode | OS2 9/125μm |
| Wavelength | 1310/1550nm |
| Insertion Loss | ≤0.3dB |
| Return Loss | ≥50dB |
| Min. Bend Radius (Fiber Core) | 10mm |
| Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
| Attenuation at 1310 nm | 0.36 dB/km |
| Attenuation at 1550 nm | 0.22 dB/km |
| Fiber Count | Duplex |
| Cable Diameter | 2.0mm |
| Cable Jacket | PVC (Riser/OFNR) |
| Polarity | A (Tx) to B (Rx) |
| Operating Temperature | -20~70°C |
| Storage Temperature | -40~80°C |
Please click the link for the attached Tech Spec: Custom Duplex Fiber Optic Patch Cable Tech Spec
Urgent order? Please contact: CustomerService@americancableassemblies.com
